The 12.7x99 SR Solid SX is a lead-free training and duty cartridge for law enforcement and military users. The twisted lead-free brass bullet has a special bullet geometry that greatly increases the air resistance of the bullet in flight. As a result, the danger zone and the maximum flight range can be reduced to 3.8 km. A corresponding weapon function from heavy machine guns of the FN Browning M2 type is guaranteed.
Product line NT
12.7x99 SR SOLID SX
45.2 g / 698 gr
Product characteristics
- Articlenumber*
- 2424330
- Product line
- NT
- Caliber
- 12,7x99
- Purpose
- Law enforcement, Military
- Bulletweight (g)
- 45.2 g
- Bulletweight (gr)
- 698 gr
- Bullet type
- Solid
- Bullet material
- Brass
- Leadfree
- Yes
- Primer cap
- SINTOX
- Case material
- Brass
- Propellant powder
- Two-base nitrocellulose powder
- Total cartridge mass (g)
- ca. 124.4 g
- Net explosive mass (g)
- ca. 16 g
- Weapon category
- Heavy machine gun
- Temperature range
- -54°C to +52°C
*article number for the smallest packaging unit
Data according to technical delivery terms
- Mean gas pressure
- max. 4,500 bar (21°C)
- Velocity measuring point
- v10
- Velocity (m/s)
- 872 m/s
- Velocity (ft/s)
- 2,861 ft/s
- Energy (J)
- 17,185 J
- Length test barrel
- 1143 mm
- Velocity measuring point tolerance (± m/s)
- 10 ± m/s
Precision data
- Accuracy type
- sx; sy
- Accuracy determination range (m)
- 300 m
- Precision requirement
- ≤ 90 mm
- Length test barrel
- 1143
- Barrel length:
- 1143 mm
- Twist length:
- 381 mm (1:15")
Ballistic data – Heavy machine gun
- Velocity measuring point type II
- v10
- Velocity (m/s)
- 872 m/s
- Weapon category
- Heavy machine gun
| Distance (m) | Velocity (m/s) | Energy (J) | Flight time (ms) | Ballistic coefficient G1 |
|---|---|---|---|---|
| 0 | 881 | 17541 | 0 | |
| 25 | 859 | 16676 | 29 | 0,345 |
| 100 | 793 | 14212 | 120 | 0,333 |
| 200 | 711 | 11425 | 253 | 0,339 |
| 300 | 635 | 9113 | 402 | 0,344 |
| 400 | 563 | 7163 | 469 | 0,339 |
| 500 | 496 | 5560 | 758 | 0,334 |
| 600 | 432 | 4218 | 974 | 0,311 |
| 700 | 375 | 3178 | 1223 | 0,288 |
| 800 | 330 | 2461 | 1509 | 0,259 |
| 900 | 300 | 2034 | 1827 | 0,251 |
| 1000 | 274 | 1697 | 2176 | 0,2 |
| 1100 | 253 | 1447 | 2557 | 0,198 |
| 1200 | 234 | 1237 | 2970 | 0,181 |
Packaging Configurations
- Packaging type
- M2A1 metal box
- Count
- 120
- Package dimension
- 31x19.5x15,5 cm
- Weight
- ca. 16,8 kg
Our portfolio
More products
warning
Fire or projection hazard.
Keep away from heat, hot surfaces, sparks, open flames and other ignition sources. No smoking. Ground and bond container and receiving equipment. Keep only in original packaging. Wear eye protection. In case of fire: Explosion risk. Evacuate area. DO NOT fight fire when fire reaches explosives. The information on the product label must always be followed.
manufacturer
RWS GmbH / Kronacher Str. 63 / 90765 Fürth / www.rws-technology.com
