The 5.56x45 FMJ M193 is probably the oldest and most widely used load in the 5.56x45 calibre. The cartridge is equally suited to tactical use and training. The 3.56 g full metal jacket soft core bullet significantly reduces wear on shooting ranges and bullet traps in a direct comparison with the SS109 or double core. Its bullet consists of a tombac jacket encasing a lead core.
Product line NT
5.56x45 FMJ (M193)
3.6 g / 55 gr
Product characteristics
- Articlenumber*
- 2425931
- Product line
- NT
- Caliber
- 5,56x45
- Purpose
- Law enforcement, Military
- Bulletweight (g)
- 3.6 g
- Bulletweight (gr)
- 55 gr
- Bullet type
- Full metall jacket-soft core
- Bullet material
- Lead / Tombac
- Bullet jacket material
- Tombac
- Bullet core material
- Lead
- Primer cap
- SINOXID
- Case material
- Brass
- Propellant powder
- Two-base nitrocellulose powder
- Total cartridge mass (g)
- ca. 12.0 g
- Net explosive mass (g)
- ca. 1.8 g
- Weapon category
- Assault rifle
- Temperature range
- -54°C to +52°C
*article number for the smallest packaging unit
Data according to technical delivery terms
- Mean gas pressure
- max. 4,050 bar (21°C)
- Velocity measuring point
- v10
- Velocity (m/s)
- 990 m/s
- Velocity (ft/s)
- 3,248 ft/s
- Energy (J)
- 1,765 J
- Length test barrel
- 508 mm
Precision data
- Accuracy type
- sV; SH
- Accuracy determination range (m)
- 300 m
- Precision requirement
- ≤ 85 mm
- Length test barrel
- 508
- Barrel length:
- 508 mm
- Twist length:
- 178 mm (1:7")
Ballistic data – Assault rifle
- Velocity measuring point type II
- v10
- Velocity (m/s)
- 915 m/s
- Weapon category
- Assault rifle
| Distance (m) | Velocity (m/s) | Energy (J) | Flight time (ms) | Ballistic coefficient G1 | Ballistic coefficient G7 |
|---|---|---|---|---|---|
| 0 | 925 | 1519 | 0 | ||
| 25 | 899 | 1435 | 27 | 0,302 | 0,157 |
| 100 | 822 | 1199 | 115 | 0,293 | 0,157 |
| 200 | 721 | 923 | 245 | 0,279 | 0,152 |
| 300 | 625 | 693 | 393 | 0,272 | 0,148 |
| 400 | 535 | 508 | 566 | 0,266 | 0,147 |
| 500 | 454 | 366 | 769 | 0,261 | 0,154 |
| 600 | 381 | 258 | 1010 | 0,238 | 0,156 |
| 700 | 324 | 186 | 1296 | 0,202 | 0,087 |
| 800 | 301 | 162 | 1618 | 0,318 | 0,128 |
| 900 | 283 | 142 | 1961 | 0,31 | 0,141 |
| 1000 | 267 | 127 | 2326 | 0,285 | 0,144 |
| 1100 | 253 | 114 | 2712 | 0,29 | 0,154 |
| 1200 | 239 | 101 | 3130 | 0,253 | 0,145 |
Packaging Configurations
Our portfolio
More products
warning
Fire or projection hazard.
Keep away from heat, hot surfaces, sparks, open flames and other ignition sources. No smoking. Ground and bond container and receiving equipment. Keep only in original packaging. Wear eye protection. In case of fire: Explosion risk. Evacuate area. DO NOT fight fire when fire reaches explosives. The information on the product label must always be followed.
manufacturer
RWS GmbH / Kronacher Str. 63 / 90765 Fürth / www.rws-technology.com
